Transmission Cooler Ford 6.0L Powerstroke 2003-2007
Regular price
$919.15
Heavy loads are no match for a 2003–2007 6.0L Powerstroke equipped with the Mishimoto 6.0 transmission cooler. Complement your cooling system with the latest addition to Mishimoto’s 6.0 Powerstroke performance parts, the all-new 6.0 transmission cooler. The stock 6.0 Powerstroke transmission cooler does an ample job of keeping temperatures down, but as the loads increase, so do transmission temps. The 37-row Mishimoto stacked plate cooler provides a larger surface area over both of the stock coolers. Core volume is increased by a whopping 21%, and fluid capacity is increased by 1/3 qt. With the Mishimoto 6.0 transmission cooler, high transmission fluid temperatures will be the least of your worries. The increased size of this 6.0L transmission cooler provides a proven 10+°F drop in transmission fluid temperature! No modifications are necessary for installation, and, just like all Mishimoto 6.0 Powerstroke parts, this cooler comes with the Mishimoto Lifetime Warranty.
Features:
- Direct fit for the 2003–2007 Ford 6.0L Powerstroke
- Proven +10°F (+5.6°C) drop in transmission fluid temperature with no additional fluid pressure drop
- No modification necessary for installation, functions with all stock equipment
- 37-row stacked plate fluid cooler provides larger surface area over even the largest stock 31-row transmission cooler
- Transmisson cooler core has a 21% increase in core volume compared to the factory 31-row transmission cooler
- Increases transmission fluid capacity by 1/3 qt
- Mishimoto Lifetime Warranty
- Will not work with vehicles that came equipped with a high mounted power steering cooler. These vehicles will need to relocate the power steering cooler to the lower mounting location.
- Material: 6061 Aluminum
- Core Height: 16.13"
- Rows: 37
- Cooler Construction: Stacked-plate
- Core Thickness: 1.25" (32mm)
- Core Length: 25.25"
- Tank Wall Thickness: .08" (2mm)
- Temp Difference: 10°F (+5.6°C) drop in transmission fluid temperature
- Overall Height: 23.5"
- Overall Length: 34"
- Overall Width: 1.34"
- Core Size: 25.25" x 16.13" x 1.25" (642mm x 410mm x 32mm)
- Inlet: .5" (13mm)
- Outlet: .5" (13mm)
- 2003–2007 Ford F-250 w/ 6.0L Powerstroke
- 2003–2007 Ford F-350 w/ 6.0L Powerstroke
- 2003–2007 Ford F-450 w/ 6.0L Powerstroke
- Also fits 1999–2003 Ford Superduty trucks with the 7.3 engine, however the transmission cooler lines must be changed to ½" OD prior to installation
- (1) Mishimoto Stacked Plate Transmission Cooler
- Mounting Hardware
- Mishimoto Lifetime Warranty
- Ford 6.0L Ford Powerstroke 2003-2007
